Dry Mortar Plant

Dispersing Machine

Dispersing Machine

Product Description

The dispersing machine is mainly suitable for coating, dye, pigment, printing ink, papermaking, adhesive and other chemical industry, stirring, dissolving and dispersing liquid and liquid solid phase material. When the equipment is stirred and dispersed, the air is sucked in very little, and the mixing and mixing effect is excellent. The mixture can be stirred evenly at low speed, and then dispersed at high speed, which can dissolve the material quickly.

Component

TONGPING machinery Co,.Ltd.

Applicable Materials

  • Ground Mortar
    Foundry sand
  • Crack Resistant Mortar
    Crack Resistant Mortar
  • Plastering Mortar
    Plastering Mortar
  • Bonded Mortar
    Bonded Mortar
  • Decorative Mortar
    Decorative Mortar
  • Masonry Mortar
    Masonry Mortar
  • Gypsum Mortar
    Gypsum Mortar

Parameter

 Name


Specification

TD-P 3000



TD-P 3000

Motor: Ant- explosion Type, Power: 30 kw ;

Rotary Speed: 0- 2500rpm (at least 1500 rpm) ;
Voltage: 380v (3-phase) ;

Lift Height: 1200 mm (Hydraulic Lifting) ;

Dispersion Disk Dia.: 400 mm ;

Mixing Volume: 3000 L ;

Electric Control Box: Inverter with control buttons (You can adjust the rotary speed according to your needs) ;
Productive power: 3T/h-5T/h

Size:2400x800x1900(mm)

TD-P 2000



TD-P 2000

Motor: Ant- explosion Type, Power: 22 kw ;

Rotary Speed: 0- 2500rpm (at least 1500 rpm) ;
Voltage: 440v (3-phase) ;

Lift Height: 1200 mm (Hydraulic Lifting) ;

Dispersion Disk Dia.: 300 mm ;

Mixing Volume: 2000 L ;

Electric Control Box: Inverter with control buttons (You can adjust the rotary speed according to your needs) ;
Productive power: 2T/h-3T/h

TD-P1000



TD-P1000

Motor: Ant- explosion Type, Power: 15 kw ;

Rotary Speed: 0- 2500rpm (at least 1500 rpm) ;
Voltage: 380v (3-phase) ;

Lift Height: 1000 mm (Hydraulic Lifting) ;

Dispersion Disk Dia.: 300 mm ;

Mixing Volume: 1000 L ;

Electric Control Box: Inverter with control buttons (You can adjust the rotary speed according to your needs) ;
Productive power: 1T/h-1.5T/h

TD-P500



TD-P500

Motor: Ant- explosion Type, Power: 7.5kw ;

Rotary Speed: 0- 2500rpm (at least 1500 rpm) ;
Voltage: 380v (3-phase) ;

Lift Height: 900mm (Hydraulic Lifting) ;

Dispersion Disk Dia.: 250 mm ;

Mixing Volume: 500 L ;

Electric Control Box: Inverter with control buttons (You can adjust the rotary speed according to your needs) ;

Productive power: 500kg/h-800kg

Mixing Bowl

mixing bowl

Φ1400x1300mm

Capacity:2000L

Mixing

mixing bowl

Φ1180x1180mm

Capacity:1000L

Mixing Bowl

mixing bowl

Φ900x1030mm

Capacity:500L
