Corn Husk Drying Production Line

Capacity: 1.53-12.14 t/h

Heat Source：Suitable for biomass, steam, natural gas and other heat sources.

Application: Widely used for drying brewery, vinass, corn husk and other materials.

Send E-mail Inquiry Now

Product Introduction

Corn husk is a valuable source of nutrients, containing not only polysaccharides like starch and cellulose, but also significant amounts of soluble protein and its degradation products, such as peptides and amino acids. Furthermore, it contains lactic acid, phytic acid, calcium, and magnesium salts, as well as soluble sugars, all of which have high nutritional value. This material can be fed to herbivores, such as cattle, sheep, and fish, as well as single-stomach animals like pigs and chickens.

Working Principle

When the moisture content of wet corn husk reaches 35% to 40%, it is uniformly mixed with corn steep liquid and conveyed into a feed machine. The wet corn husk and corn steep liquid mixture is then delivered into a drying drum, which contains uniformly distributed flights and sets of agitators. These agitators lift the wet corn husk up and down, ensuring it comes into full contact with hot air, allowing for the process of mass transfer and heat transfer to occur.

Parameter

Model	Input (t/h)	Output (t/h)	Evaporation Capacity (t/h)	Total Power (kw)	Total Weight (kg)	Plant Area (m²)	Initial Moisture (%)	Final Moisture (%)	Drying Temperature (℃)
TDFPS108	1.53	1.08	0.45	34	22000	5m*15m	40±5%	15% (Adjustable)	280±30
TDFPS203	2.89	2.03	0.85	45	28000	6m*22m
TDFPS367	5.2	3.67	1.53	78	40000	8m*16m
TDFPS468	6.63	4.68	1.95	90	45000	8m*18m
TDFPS511	7.24	5.11	2.13	105	50000	8m*20m
TDFPS629	8.91	6.29	2.62	125	60000	10m*20m
TDFPS741	10.5	7.41	3.09	140	68000	10m*24m
TDFPS857	12.14	8.57	3.57	155	76000	10m*24m
